LFB-4H 4 Side Powder Automatic Packing Machine
LFB-4H
LFB-4H 4 Side Powder Automatic Packing Machine
Maximum Production Speed:10-30g (depending on the size of the product being inspected)

There are so many innovative features of this automatic powder packing machine. This machine is suitable for medicine, coffee, condiments, sugar, powdered tea, granules, medical supplies, powdered milk, supplements for diet, health supplements, and other relevant powdered products.


Category: Multi-Stick Automatic Packing Machine, 4 Side Powder Automatic Packing Machine

Model

LFB-4H

Object

Powder

Volume

10-30g

Packing Size

W:75-120mm L:85-180mm (Single Bag)

Packing Way

4-sides Sealing

Measurement

±2%

Cutting Way

Parallel

Film Materials

AL, NY, PE & other available for heat sealing films

Speed

25-40 cut/min

Weight

1800kg

Power Consumption

220~420V, 3Ph, 50~60Hz

Air Consumption

0.4-0.7Mpa800-1000L/min

See More
————— Details —————

Description of LFB-4H 4 Side Powder Automatic Packing Machine

In a word, the advantages of this automatic powder packing machine are as follows.  Provisions are made in the machine for intelligent protection to maximize the yield and reduce wastage while maintaining machine stability. The machine will automatically stop functioning and display the failure information in the event of temperature control failure, heater burn-out failure, photo-electric failure, or even when the machine runs out of the film.



All these advanced features make the machine very stable and easy to use, thus resulting in high yield and low wastage at a very attractive cost. This machine can use for many kinds of powder, such as being a coffee powder packing machine.




Machine Features of LFB-4H 4 Side Powder Automatic Packing Machine

1. Automatic Rectification

The film board can be adjusted from left to right, the photocell can be calibrated.

2. Accurate Packing

Highly precise I-MARK sensing and servo drive lead to precise packing as well as less noise.

3. Adjustable Packing Length

Packing length can be adjusted by touching a monitor which enables by an independent Servo Motor.

4. Twice Sealing

This 4-side seal packaging machine seals products twice consecutively for perfect sealing. The product cutting is being done at the same time the machine does the secondary sealing.

5. The alarm of Replace Film

The alarm gives notice 2 minutes before the film is finished When the film is completely consumed, the machine will stop at its designated position.

6. Safety Assurance

A variety of safety devices are  installed in a machine and alert when any doors open or hot-wire are snapped via buzzer sounds.



Functions of LFB-4H 4 Side Powder Automatic Packing Machine


  • Round-cutting Edge

  • Laser printer prints tearing-line

  • Faulty weight product detection and rejection

  • Sealing Edge: Straight line or Serrated

  • Out-feeding: Integrated line or single machine out-feed

  • Double-Tearing Area

  • Empty stick rejection

  • Sealing: Diamond Seal or Stripes

  • Different in-feeding devices available according to different materials and characteristics


Solution

We know that every business is different. That’s why we provide a variety of custom packaging equipment that meets the unique needs of our clients.



Industry Application

Mode: LFB-4H

Function: LFB-4H  is a 4-side seal powder packaging machine. Apply to tea, coffee, condiments, sugar, granules, medical supplies, tablets, powdered milk, vitamin, health supplements, and other relevant powdered products.



How Pharmapack  4-Side Seal Powder Packaging Machine Can Help Your Production

Pharmapack automatic powder packing machine is suitable for packing powder products such as milk powder, wheat flour, coffee powder, tea powder, bean powder. Also suitable for packing chips, nuts, dried fruits, coffee beans, and other granular solids.




Why Choose Pharmapack Machine

 Experienced R&D Group

PharmaPack congregates advanced technology in the world to supply the most advanced and guaranteed technical support for our customers.



  One-stop Service System

Pharmapack can supply the most perfect "turn-key" packaging solutions for every customer.


 Industry-leading Technology

New servo control with self-detection to replace the old cylinder, the flapper free of dust effect, more stable, longer life-span, lower maintenance cost.

   Excellent Quality Control

Tested by internationally certified companies, Pharmapack equipment has passed the evaluation of CE, UL Certify, CSA and complies with GAMP, FDA (CFR21), cGMP, and TGA standards.
