Model | LFIM-01-BFS |
| Stable Speed | 600 EA (120 trays) / minute |
| Applicable Specifications | per Unit 0.5 - 10ML |
| Inspection Scope | Fill volume, missing tubes, punching defects, black spots, foreign particles,hair, leaks, etc. |
| Inspect Accuracy | Visual: >45 um Vacuum: >5 um High-Voltage: >0.2 um |
| Power Supply | AC 380V,50/60 Hz |
| Air Consumption | Approx. 20 L/min |
| Wattage | 10 KW |
| Air Pressure | 0.5~0.7Mpa |
| Dimensions (L*W*H) | 2450mmx1500mmx1915mm |
| Weight | Approx.2500 kg |
Integrates dual leak Inspection (High-voltage+Vacuum) with Al visual andMagnetic Levitation technology. Performs high-speed, non-destructive360° inspection. Full automation in control, tracking, and sorting ensuresimprove efficiency and quality compliance with GMP standards.
